Structure Design
In VirtualLab Fusion the user can design phase functions, which works as beam shaper, beam splitter and diffuser, using the iterative Fourier transformation algorithm. Later these phase function can be converted into a optical structure, which can be a diffractive mirror or a transparent plate. VirtualLab offers a convenient tool to design such an optical structure from a given phase function. This use case shows the usage of the structure design tool.
- Learn more (PDF) pdf 14.11.22
- Sample files in VirtualLab Fusion (ZIP) zip 14.11.22
